Compressor Drive Kits - TGM I . . . 05.05 > 01.20 - 19 501 074
Part number
19 501 074
Designation
Drive kit
Specifications
SD5H14 / SD5L14
SD7H15 / SD7L15
QP-13 / TM-13
QP-15 / TM-15
QP-16 / TM-16
SD7H15 / SD7L15
QP-13 / TM-13
QP-15 / TM-15
QP-16 / TM-16
Original number
Oliva Torras . . . KC06040074
Refrigerant
-
OEM number
---
Note
For use with :
Sanden . . . SD5H14 / SD5L14
Sanden . . . SD7H15 / SD7L15
Clutch A2 . . . ø 132 mm
Que . . . QP-13 / Valeo . . . TM-13
Que . . . QP-15 / Valeo . . . TM-15
Que . . . QP-16 / Valeo . . . TM-16
Clutch A2 . . . ø 135 mm
And any compressor with the same mounting size and gauge line
Compressor speed . . . 3300 rpm
Sanden . . . SD5H14 / SD5L14
Sanden . . . SD7H15 / SD7L15
Clutch A2 . . . ø 132 mm
Que . . . QP-13 / Valeo . . . TM-13
Que . . . QP-15 / Valeo . . . TM-15
Que . . . QP-16 / Valeo . . . TM-16
Clutch A2 . . . ø 135 mm
And any compressor with the same mounting size and gauge line
Compressor speed . . . 3300 rpm
Application list
MAN . . . TGM . . . 05.05 > 01.20
. . . . . . . . . 240 . . . Engine D 0836 LFL 40 [Euro III] . . . 6 / 6871 cm³ . . . 240 HP . . . 04.05 - 09.06 . . . 12.240, 13.240, 15.240, 18.240, 22.240
. . . . . . . . . 240 . . . Engine D 0836 LFL 50 [Euro IV] . . . 6 / 6871 cm³ . . . 240 HP . . . 04.06 - . . . 12.240, 13.240, 15.240, 18.240, 22.240
. . . . . . . . . 250 . . . Engine D 0836 LFL 60 [Euro V] [EEV] [Euro VI] . . . 6 / 6871 cm³ . . . 250 HP . . . 2009 - . . . 13.250, 15.250, 18.250, 22.250
. . . . . . . . . 250 . . . Engine D 0836 LFL 63 [Euro V] [EEV] [Euro VI] . . . 6 / 6871 cm³ . . . 250 HP . . . 2009 - . . . 13.250, 15.250, 18.250, 22.250
. . . . . . . . . 280 . . . Engine D 0836 LFL 41 [Euro III] . . . 6 / 6871 cm³ . . . 280 HP . . . 04.05 - 09.06 . . . 12.280, 13.280, 15.280, 18.280, 22.280, 26.280
. . . . . . . . . 280 . . . Engine D 0836 LFL 51 [Euro IV] . . . 6 / 6871 cm³ . . . 280 HP . . . 04.06 - . . . 12.280, 13.280, 15.280, 18.280, 22.280, 26.280
. . . . . . . . . 290 . . . Engine D 0836 LFL 60 [Euro VI] . . . 6 / 6871 cm³ . . . 290 HP . . . 2013 - . . . 13.290, 15.290, 18.290, 22.290
. . . . . . . . . 290 . . . Engine D 0836 LFL 63 [Euro VI] . . . 6 / 6871 cm³ . . . 290 HP . . . 2013 - . . . 13.290, 15.290, 18.290, 22.290
. . . . . . . . . 330 . . . Engine D 0836 LFL 44 [Euro III] . . . 6 / 6871 cm³ . . . 326 HP . . . 04.05 - 09.06 . . . 15.330, 18.330, 26.330
. . . . . . . . . 330 . . . Engine D 0836 LFL 52 [Euro IV] . . . 6 / 6871 cm³ . . . 326 HP . . . 04.06 - . . . 15.330, 18.330, 26.330
Only for vehicles without original option MAN FF120
IMPORTANT: The kit is not suitable for the new Engines:
D0836LFL79 / D0836LFL80 / D0836LFL81
With or without A/C
MAN . . . TGM . . . 05.05 > 01.20
. . . . . . . . . 240 . . . Engine D 0836 LFL 40 [Euro III] . . . 6 / 6871 cm³ . . . 240 HP . . . 04.05 - 09.06 . . . 12.240, 13.240, 15.240, 18.240, 22.240
. . . . . . . . . 240 . . . Engine D 0836 LFL 50 [Euro IV] . . . 6 / 6871 cm³ . . . 240 HP . . . 04.06 - . . . 12.240, 13.240, 15.240, 18.240, 22.240
. . . . . . . . . 250 . . . Engine D 0836 LFL 60 [Euro V] [EEV] [Euro VI] . . . 6 / 6871 cm³ . . . 250 HP . . . 2009 - . . . 13.250, 15.250, 18.250, 22.250
. . . . . . . . . 250 . . . Engine D 0836 LFL 63 [Euro V] [EEV] [Euro VI] . . . 6 / 6871 cm³ . . . 250 HP . . . 2009 - . . . 13.250, 15.250, 18.250, 22.250
. . . . . . . . . 280 . . . Engine D 0836 LFL 41 [Euro III] . . . 6 / 6871 cm³ . . . 280 HP . . . 04.05 - 09.06 . . . 12.280, 13.280, 15.280, 18.280, 22.280, 26.280
. . . . . . . . . 280 . . . Engine D 0836 LFL 51 [Euro IV] . . . 6 / 6871 cm³ . . . 280 HP . . . 04.06 - . . . 12.280, 13.280, 15.280, 18.280, 22.280, 26.280
. . . . . . . . . 290 . . . Engine D 0836 LFL 60 [Euro VI] . . . 6 / 6871 cm³ . . . 290 HP . . . 2013 - . . . 13.290, 15.290, 18.290, 22.290
. . . . . . . . . 290 . . . Engine D 0836 LFL 63 [Euro VI] . . . 6 / 6871 cm³ . . . 290 HP . . . 2013 - . . . 13.290, 15.290, 18.290, 22.290
. . . . . . . . . 330 . . . Engine D 0836 LFL 44 [Euro III] . . . 6 / 6871 cm³ . . . 326 HP . . . 04.05 - 09.06 . . . 15.330, 18.330, 26.330
. . . . . . . . . 330 . . . Engine D 0836 LFL 52 [Euro IV] . . . 6 / 6871 cm³ . . . 326 HP . . . 04.06 - . . . 15.330, 18.330, 26.330
Only for vehicles without original option MAN FF120
IMPORTANT: The kit is not suitable for the new Engines:
D0836LFL79 / D0836LFL80 / D0836LFL81
With or without A/C
