Ricambi >
Kit Staffaggi Compressori >
CITROËN >
Jumper / Relay II . . . (250) . . . 04.06 > 09.19 >
19 151 390
Kit Staffaggi Compressori - Jumper / Relay II . . . (250) . . . 04.06 > 09.19 - 19 151 390
Articolo
19 151 390
Designazione
Kit motore
Specificazioni
SD5H14 / SD5L14
SD7H15 / SD7L15
QP-13 / TM-13
QP-15 / TM-15
QP-16 / TM-16
SD7H15 / SD7L15
QP-13 / TM-13
QP-15 / TM-15
QP-16 / TM-16
Numero originale
Oliva Torras . . . KC15050390
Refrigerante
-
Numero OEM
---
Nota
Supplied with special clutch pulley for :
Que . . . QP-13 / Valeo . . . TM-13
Que . . . QP-15 / Valeo . . . TM-15
Que . . . QP-16 / Valeo . . . TM-16
Compressor speed . . . 3150 rpm
Available on request without clutch pulley for use with :
Sanden . . . SD5H14 / SD5L14, SD7H15 / SD7L15
Clutch P7 or P8 . . . ø 119 mm
Seltec . . . . TM-13, TM-15, TM-16
Clutch P6 or P8 . . . ø 119 mm
And any compressor with the same mounting size and gauge line
Que . . . QP-13 / Valeo . . . TM-13
Que . . . QP-15 / Valeo . . . TM-15
Que . . . QP-16 / Valeo . . . TM-16
Compressor speed . . . 3150 rpm
Available on request without clutch pulley for use with :
Sanden . . . SD5H14 / SD5L14, SD7H15 / SD7L15
Clutch P7 or P8 . . . ø 119 mm
Seltec . . . . TM-13, TM-15, TM-16
Clutch P6 or P8 . . . ø 119 mm
And any compressor with the same mounting size and gauge line
Elenco delle applicazioni
CITROËN . . . Jumper / Relay II . . . (250) . . . 04.06 > 09.19
. . . . . . . . . . . . . 2.0 Blue HDi 110 . . . Engine DW10 [Euro 6] . . . 4 / 1997 cm³ . . . 110 HP . . . 11.15 - 09.19
. . . . . . . . . . . . . 2.0 Blue HDi 130 . . . Engine AHN (DW10FUD) [Euro 6] . . . 4 / 1997 cm³ . . . 130 HP . . . 11.15 - 09.19
. . . . . . . . . . . . . 2.0 Blue HDi 163 . . . Engine AHP (DW10FUC) [Euro 6] . . . 4 / 1997 cm³ . . . 163 HP . . . 11.15 - 09.19
NOT compatible with 4x4
- If the vehicle is equipped with the Start & Stop,
the vehicle must be equipped from factory with Conversion interface Box JI01 option (connector 15 ways C036L1A)
See our Stop & Start deactivation kits chapter to select the needed kit
With A/C
CITROËN . . . Jumper / Relay II . . . (250) . . . 04.06 > 09.19
. . . . . . . . . . . . . 2.0 Blue HDi 110 . . . Engine DW10 [Euro 6] . . . 4 / 1997 cm³ . . . 110 HP . . . 11.15 - 09.19
. . . . . . . . . . . . . 2.0 Blue HDi 130 . . . Engine AHN (DW10FUD) [Euro 6] . . . 4 / 1997 cm³ . . . 130 HP . . . 11.15 - 09.19
. . . . . . . . . . . . . 2.0 Blue HDi 163 . . . Engine AHP (DW10FUC) [Euro 6] . . . 4 / 1997 cm³ . . . 163 HP . . . 11.15 - 09.19
NOT compatible with 4x4
- If the vehicle is equipped with the Start & Stop,
the vehicle must be equipped from factory with Conversion interface Box JI01 option (connector 15 ways C036L1A)
See our Stop & Start deactivation kits chapter to select the needed kit
With A/C
